Item Details

Highlights

• A barcode scanner is an electronic device for reading printed barcodes
• Like a flatbed scanner,it consists of a light source
• a lens and a light sensor translating optical impulses into electrical ones
• Nearly all barcode readers contain decoder circuitry analyzing the barcode's image data provided by the sensorsending the barcode's content to the scanner's output port.
• SUPC: SDL050465876

Technical Specification

IN THE BOX Sales Package Main Unit

GENERAL Brand TVS Model BS-C 101 Star Type Barcode Scanner Colour Black

SPECIFICATIONS Number of Pixels 2500 pixels Light Source 617 nm visible LED Image Catch Analog Microprocessor 32 bit Depth of Field 0 - 300 mm (UPC/EAN 100 Percent, PCS: 90 Percent) Scan Angle 42 Degree Scan Rate 330 scans per second Minimum Bar Width 0.1 mm (4 mil) (0.07 mm actually) (Code 39, PCS: 90 Percent), More than 100 mm on 0.125 mm barcode Print Contrast Min. 30 Percent at UPC/EAN 100 Percent Indicators Blue LED Beeper Operation Programmable tone and beep time System Interfaces Keyboard, RS-232C, HID USB, USB virtual COM port, Wand Cable Field Replaceable, Standard 2.0M Straight Regulatory EMC: CE and FCC DOC Compliance, VCCI, BSMI Decoding Capability Barcodes Code 39, Code 39 Full ASCII, Code 32, Code 128, UCC/EAN-128, Codabar, Code11, Code 93, Standard 2 of 5, Industrial 2 of 5, Interleaved 2 of 5, China Postal Code, IATA, UPC/EAN/JAN, UPC/EAN/JAN with Addendum, Telepen, MSI/Plessey, GS1DataBar (RSS) Linear, Linear-stacked

POWER REQUIREMENT Power Input Input Voltage: 5 V DC +/- 5 Percent, Operating Current: 100 mA typical

OPERATING ENVIRONMENT Temperature Operating: 0 Degree C - 50 Degree C (32 Degree F - 122 Degree F), Storage: -20 Degree C - 60 Degree C (-4 Degree F - 140 Degree F) Humidity 5 Percent - 95 Percent RH (non-condensing) Ambient Light Immunity 0 - 10000 Lux Drop Durability Designed to withstand 1.5 M drops

ADDITIONAL FEATURES Features Aim and Shoot Trigger - Gives operational comfort and reduces fatigue especially in peak hours; Durable and Strong Design - Designed to with stand multiple drops from a height of 5 feet; Plug and Play; Auto Sense/Hands Free

PHYSICAL SPECIFICATIONS Dimension (L x W x H): 152.3 x 64.4 x 104.9 mm (device only) Weight 120 g (device only)

Description

With Ultra scan decoding technology that can decode a majority of 1D barcodes as well as GS1 Data Bar, TVS BS-C 101 Star has a plug and play design that is durable and can withstand drop from 5 feet.
The BS-C101 Star Advantage
TVS Electronics BSC-101 Star is a high speed CCD scanner. It has a scan rate of 330 scans per second, which is the highest among its competitors. Empowered with Ultra scan decoding technology it can decode a majority of 1D barcodes as well as GS1 Data Bar.



It supports auto scan mode and with an optional stand can work as a hands free scanner. It has a 32 bit microprocessor, which guarantees an unbeatable scan rate and decoding accuracy. The BS-C101 Star is suitable for a wide range of applications, from retail checkout and inventory management, to invoicing in offices and shipping receiving control in factories.



Number of Pixels - It has 2500 pixels which increases the resolution of the scanner and helps in better decoding of Barcodes.



High Scan Rate - The scan speed of 330 scans per second is highest in this category of scanners making it the fastest in its class



High Depth of Field - Depth of field of up to 300 mm enables decoding from larger distances.



Lower PCS (Print Contrast- Signal) - Lower PCS pixels decodes faded barcodes.



Auto Sense / Hands Free - It is enabled with auto sense technology making it convenient to use in Hands free mode.



Rugged Body - Able to withstand drops of up to 1.5 m
